SWL
SWL Screw jack
The SWL Worm Screw Jack is a reliable lifting and positioning device designed for accurate load lifting, lowering, and height adjustment. It features a compact structure, stable performance, and precise control, making it suitable for various industrial lifting and positioning applications.
SWL Worm Screw Jack
Product Specifications
- Product Name: SWL Worm Screw Jack
- Material:
- Screw & worm: 45# steel
- Worm gear: High-strength bronze alloy
- Housing: Cast iron/Cast Steel
- Stroke: Customized according to application requirements
- Drive Method: Electric motor driven or manual operation
Product Features
- High-Strength Materials The screw and worm are manufactured from 45# steel, providing excellent strength and wear resistance. The bronze worm gear ensures smooth transmission, good self-lubrication, and long service life.
- Compact & Rigid Structure The cast iron housing offers high rigidity and durability while maintaining a compact size, making the jack easy to install in limited spaces.
- Precise Lifting & Positioning Designed to accurately control and adjust lifting height, suitable for applications requiring precise positioning and stable operation.
- Multiple Drive Options Can be operated by electric motor for automated lifting or manual handwheel for simple and flexible control.
- Customizable Stroke The lifting stroke can be customized to meet different load and installation requirements.
Functions
- Lifting and lowering heavy loads
- Precise height adjustment and positioning
- Load holding with stable performance
Applications
- Industrial machinery
- Metallurgy equipment
- Construction machinery
- Water conservancy and hydraulic equipment
