SRC Gearbox
SRC Helical Gear Reducer
The SRC Helical Gear Reducer features a highly modular design, allowing flexible combinations with a wide range of motors including standard IEC, brake, explosion-proof, variable-frequency, and servo motors. This series is widely used in traditional industries such as textiles, food, ceramics, packaging, logistics, and plastics, and offers multiple flange and foot mounting options for customized reducer configurations.
SRC Helical Gear Reducer
Product Features
- Modular Design: Multiple structural configurations can be achieved by combining different foot and flange options
- Gear Quality: High-precision ground helical gears with hardened surfaces for durability and long service life
- Compact & Lightweight: Aluminum housing reduces weight without compromising strength
- Versatile Mounting: Supports multiple installation positions for flexible system integration
- Wide Power & Ratio Range: 4 models covering 0.12–4 kW, ratios 3.66–54, maximum torque 120–500 Nm
- Customizable Configurations: Adaptable to user requirements with modular assembly
Technical Parameters
Parameter | Description |
|---|---|
Model | SRC 01/ SRC 02/ SRC 03 / SRC 04 |
Power | 0.12 – 4 kW |
Reduction Ratio | 3.66 – 54 |
Max Torque | 120 – 500 Nm |
Gear Type | Ground helical gears |
Housing Material | Aluminum alloy |
Motor Compatibility | IEC standard / Brake / Explosion-proof / VFD / Servo |
Mounting Type | Foot / Flange / Multi-position |
Efficiency | High mechanical efficiency |
Noise Level | Low vibration and low noise |
Lubrication | Oil bath lubrication |
