Harmonic Reducer-LSS Series
The LSS Series is an integrated, user-friendly harmonic drive solution, designed for easy installation and reliable operation. Each model is equipped with a high-rigidity cross roller bearing, allowing it to directly support external loads without additional bearing arrangements. This series requires high installation precision and is suitable for advanced mechanical design capabilities and precision assembly conditions.
Harmonic Reducer-LSS Series
Key Features
- Three-component structure: flexspline, circular spline, and wave generator
- Compact and lightweight design
- Ideal for space- and weight-critical applications
- High transmission accuracy
- Requires precise installation and alignment
Technical Parameters
Parameter | Description |
|---|---|
Type | LSS |
Reduction Ratio | 8 / 11 / 14 / 17 / 20 / 25 / 32 / 40 |
Rated Torque | Depends on model |
Peak Torque | Depends on model |
Backlash | ≤ 20 arcsec |
Input Speed | Up to 2000 rpm |
Efficiency | Up to 90% |
Lubrication | Grease lubrication |
Applications
- Industrial robots
- Automation and positioning systems
- CNC and machine tools
- Semiconductor and precision equipment
